XLJ205-B 高速包覆丝机/ XLJ205-B Yarn Covering Machine Spandex yarn covering machine Metallic yarn covering machine (MH/MX) 用途:XLJ205- B 包覆丝机适用于氨纶丝为芯丝,涤纶,棉纶,棉纱为外包纱单双包覆机生产,特别适用于芯丝为20D-100D,外包纱12D-300D包覆机。 Ues: XLJ205 – B Yarn covering machine is used for the single and double covering production of covered yarn with spandex as the core yarn. Especially for 20 D-100D as core yarn and 12D-300D as outer covering yarn. And it can also used for the single and double covering with metallic yarn covering. 技术参数/ Technical Specifications 型式/Type | 双面双层/Two sides and Two layers | 外型尺寸Size(mm) L×W×H | 16700×1400×2100 | 全机总功率KW Total power (kw) | 13 | 锭数Spindle Number | 256/192 | 机械定速r/min Mechanical Spindle Speed (r/min) | 9000 ~ 22000 | 包覆捻度范围 T/M Range Of Covering Twist Number(T/M) | 200 ~ 3000 | 捻向 Twist Direction | S 或者 Z S or Z | 外包丝筒子尺寸 Covering Fiber Bobbin Size | Φ84×Φ36×140 | 芯纱牵伸范围 Range Of Max. Stretching (Times) | 1.6 ~ 4.5 | 外包丝容量Capacity Of Covering Fiber | 750 | 卷取成型方式Take-Up Forming Mode | 机械成型 Mechanically Forming |
|
