筒管规格 Bobbin spec | 10"(280mm-300mm) |
结构 Layout | 双面机,每台(4-36)锭 Double-sided, one-machine has (4-36) spindles |
电源 Power Supply | 三相380V 50/60HZ/Three phases 380V 50/60HZ |
驱动 Transmission | 单锭独立交流马达驱动 Every spindle is driven by a AC motor individually |
消耗功率 Power Comsumption | 0.18千瓦/锭/0.18KW/spindle |
成型筒子 Take-up package | 圆形柱(0°)/Cylinrical (0°)锥形; cone |
筒子直径 Package Diameter | 最大200和300毫米/Max.200and 290mm |
纱线速度范围 Yam speed | 300-1000m/min |
电子防重叠装置 Electrical wobble frequency anti-patterning function | 变频器控制/Control by the lnverter |
定长装置 Length counting device | 可编程控制器(PLC)集中控制/显示计长 Controlled and displayed by PLC |
张力器 Yarn tension and waxer adjusting device | 每锭配置旋转自清洁张力器和上腊 Every spindle has a self-cleaning yarn tension and waxer adjusting device |
机械清纱装置 Slub-Catcher | 每锭配置可微调机械清纱刀 Every spindle has a Mechanical Slub-Catcher |
断纱自停装置 Yarn break control device | 电子断纱自停 The spindle will stop when the yarn breaks by a yambreak control device |
调速装置 Speed Regulation | 变频调速/By inverter |
电子式清纱装置 Electronic Slub-Catcher | 可选配/Ordered separately |
空气捻接器 Splicer | 可选配/Ordered separately |
照明系统(带灯) Lighting system | 可选配/Ordered separately |
外形尺寸(毫米) Dimensions | 1920(长/length)×850(宽/width)×1650(高/height)mm 4锭尺寸 |
